Rear Shelf: Procedures

REMOVAL

1. Remove the rear seat cushion.

2. Remove the nut from each side.
3. Remove the seat backrest.
4. Remove the roof side rear trim panels.

5. Remove the screw from each side.

6. Remove the high mounted stoplamp.

7. Remove the high mounted stoplamp brackets.
