Crown Victoria V8-4.6L VIN W (2000)
Ball Joint: Specifications
Front Lower Ball Joint
Measurement .................................................................................................................................................. Between lower control arm and knuckle
Deflection ........................................................................................................................................................................................ 0-0.012 in (0-0.3mm)
Reference Diagram ...................................................... B - but a jackstand must be placed under the lower control arm to "load the suspension".
Front Upper Ball Joint
Measurement .................................................................................................................................................. Between upper control arm and knuckle
Deflection ........................................................................................................................................................................................ 0-0.008 in (0-0.2mm)
