E 150 V8-4.6L (2007)
Parking Assist Control Module: Service and Repair
PARKING AID MODULE
Removal and Installation
1. Remove the steering column opening cover.
2. Remove the instrument panel LH knee bolster.
3. Disconnect the parking aid module electrical connector.
4. Disconnect the parking aid speaker electrical connector.
5. Remove the 2 bolts and the parking aid module.
6. To install, reverse the removal procedure.
