E 150 V8-4.6L (2007)
10. Remove the cushion outboard side shield rear screw from under the seat.
If the seat is not equipped with a power seat track, remove the cushion outboard side shield.
Seats with power
11. Remove the cushion outboard side shield front screw and position aside the side shield.
All seats
12. WARNING: Use care when the seat back frame is removed and when releasing the recliners from a backrest upright position. The recliners are
spring-loaded, which may cause the recliner upper arms to fold with significant speed/force. Failure to follow this instruction may result in serious
personal injury.
Remove the 2 recliner bolts from the recliner assembly.
To install, tighten to 48 Nm (35 lb-ft).
