E 150 V8-4.6L (2007)
^
To install, tighten to 95 Nm (70 ft. lbs).
9. Support the rear of the transmission with a safety stand.
10. NOTE: RH shown, LH similar.
Remove the RH and LH transmission crossmember-to-frame nuts and bolts and remove the transmission crossmember.
^
To install, tighten to 81 Nm (60 ft. lbs).
11. Remove the 4 exhaust Y-pipe-to-exhaust manifold nuts and discard. Remove the exhaust Y-pipe.
^
To install, tighten the upper exhaust Y-pipe-to-exhaust manifold nuts to 40 Nm (30 ft. lbs.) then tighten the lower exhaust Y-pipe-to-exhaust
manifold nuts to 40 Nm (30 ft. lbs).
12. If installing a new exhaust Y-pipe, remove the heated oxygen sensors (HO2S).
^
Apply a light coat of high temperature nickel anti-seize lubricant to the HO2S threads prior to installation.
^
To install, tighten to 46 Nm (34 ft. lbs).
13. To install, reverse the removal procedure.
