E 150 V8-4.6L (2007)
Center Mounted Brake Lamp: Service and Repair
HIGH MOUNTED STOPLAMP
Removal and Installation
High mounted stoplamp with attached cargo lamp
1. Remove the 2 screws and the cargo lamp lens.
2. Remove the 2 screws and position the cargo lamp assembly aside.
-
Remove the 2 bulb sockets from the high mounted stoplamp assembly.
3. Remove the 2 screws and the high mounted stoplamp assembly.
High mounted stoplamp without attached cargo lamp
