E 150 V8-4.6L (2007)
8. NOTE: Use either a high-ratio, electric or battery-operated caulk gun that will apply the urethane with less effort and continuous bead. Apply
urethane adhesive on top of the existing trimmed urethane adhesive bead on the pinch weld. Make sure that all gaps in the urethane adhesive are
smoothed into one continuous bead starting and ending at the bottom of the windshield near the center.
9. CAUTION: After replacing the urethane-installed glass, the vehicle must not be driven until the urethane has cured. Inadequate curing
of the urethane can adversely affect the strength of the urethane sealant bond.
NOTE: Before installing the windshield glass, open the windows to prevent the windshield glass from being pushed out by air pressure if a door
is closed.
Install the windshield glass.
10. Fill the cavities between both the LH and RH sides of the windshield header seal and the sheet metal, using urethane adhesive for a total length of
50 mm (1.96 in) from the base of the A-pillars.
11. Install the inside rear view mirror.
12. Install the roof trim panel.
13. Install the LH and RH A-pillar mouldings.
14. Install the cowl grille panel.
15. Install the windshield wiper arms.
