E 250 V8-4.6L SOHC VIN W (2004)
Brake Pedal Assy: Service and Repair
Brake Pedal and Bracket
Removal and Installation
1. Disconnect the battery.
2. Release the fuse block assembly from the brake pedal bracket and position aside.
3. Disconnect the brake booster push rod.
1
Remove the stoplamp switch self-locking clip.
2
Remove the stoplamp switch.
3
Remove the brake booster push rod bushing.
4
Disconnect the brake booster push rod from the brake pedal pin.
