E 450 V10-6.8L (2008)
Vehicle Lifting: Description and Operation
JACKING AND LIFTING
WARNING:
-
When jacking or lifting the vehicle, block all wheels remaining on the ground. Set the parking brake if the rear wheels will remain on the
ground. These actions help prevent unintended vehicle movement. Failure to follow these instructions may result in serious personal
injury.
-
Never get underneath a vehicle that is supported only by a jack. The jack could unintentionally lower. Always support vehicle with floor
stands. Failure to follow these instructions may result in serious personal injury.
-
Only raise the vehicle when positioned on a hard, level surface. Attempting to raise the vehicle on an uneven or soft surface may result in
vehicle slipping or falling from the jack or jackstand. Failure to follow this instruction may result in serious personal injury.
CAUTION: Damage to suspension, exhaust and steering linkage components can occur if care is not exercised when positioning the hoist
adapters prior to lifting the vehicle.
Frame Lifting Points
Front Lifting Points
