Econoline E250 3/4 Ton V8-4.6L SOHC VIN W (2000)
Rear Door Latch: Service and Repair
Double Latch Hinged Door
Lower Latch
REMOVAL
1. Remove the door trim panel and watershield.
2. Disengage the lower cable keeper by pushing the bottom keeper end up and sliding the keeper toward the outside of the door.
3. Disengage the cable from the door handle.
4. Remove the bolts, and remove the lower latch and cable.
INSTALLATION
