Econoline E250 3/4 Ton V8-4.6L SOHC VIN W (2000)
Piston: Specifications
Diameter
Coded Red 1
3.550 - 3.551 in
Coded Blue 2
3.5507 - 3.5515 in
Coded Yellow 3
3.513 - 3.5521 in
Piston-to-Bore-Clearance
0.0005 - 0.001 in
Pin Bore Diameter
0.866 - 0.8663 in
Ring Groove Width
Compression (Top)
0.06 - 0.610 in
Compression (Bottom)
0.060 - 0.0602 in
Oil Ring
0.275 - 0.2844 in
