Econoline E250 3/4 Ton V8-4.6L SOHC VIN W (2000)

Page 1
background image

Piston Pin: Specifications



Piston Pin- Length

2.44 - 2.443 in







Diameter

0.866 - 0.8661 in







Pin to Piston Clearance

0.0002 - 0.0004 in







Pin to Rod Clearance

0.0006 - 0.00157 in
