Econoline E250 3/4 Ton V8-4.6L SOHC VIN W (2000)

Page 1
background image

Piston Ring: Specifications



Ring Gap

Compression (Top)

0.01 - 0.02 in









Compression (Bottom)

0.01 - 0.02 in











Oil Ring (Steel Rail)

0.006 - 0.026 in











Oil Ring

Snug Fit









Oil Ring Service Limit

0.0006 in
