Econoline E250 3/4 Ton V8-4.6L SOHC VIN W (2000)
6. Remove the two A/C condenser mounting brackets.
1
Remove the screw.
2
Remove the A/C condenser mounting bracket.
7. Remove the A/C condenser core.
CAUTION: Do not damage the cooling fins while handling the A/C condenser core.
8. Remove the two seals.
1
Remove the eight retaining pins.
2
Remove the two seals.
INSTALLATION
1. Service the new A/C condenser core with the correct amount of PAG compressor oil, YN-12c, F7AZ-19589-DA, or equivalent meeting ford
specification WSH-M1C231-B. See: Service and Repair/Refrigerant Oil Addition
2. Install the two seals
1
Install the two seals.
2
Install the eight retaining pins.
3. Install the A/C condenser core.
CAUTION: Do not damage the cooling fins while handling the A/C condenser core.
