Econoline E250 3/4 Ton V8-4.6L SOHC VIN W (2000)
9. Disconnect the underbody tube spring lock coupling.
10. Lower the vehicle.
11. Remove the condenser to evaporator tubes.
INSTALLATION
1. Service the new condenser to evaporator tube with the correct amount of PAG compressor oil, YN-12c, F7AZ-19589-DA, or equivalent meeting
Ford specification WSH-M1C231-B. See: Service and Repair/Refrigerant Oil Addition
2. Route the condenser to evaporator tube.
3. Raise the vehicle.
4. Connect the underbody tube spring lock coupling.
5. Lower the vehicle.
6. Connect the A/C.evaporator core fitting.
1
Lubricate the new O-ring seals with PAG compressor oil, YN-12c, F7AZ-19589-DA, or equivalent meeting Ford specification
WSH-M1C231-B and install the O-ring seals.
2
Connect the A/C evaporator core fitting.
3
Install the screw.
CAUTION: Use a wrench on each side of the fitting to prevent damage to the A/C fitting.
