Econoline E250 3/4 Ton V8-4.6L SOHC VIN W (2000)
4. For the A/C condenser core, add 30 ml (1 ounce) of clean PAG Refrigerant Compressor Oil (R- 134a Systems) F7AZ-19589-DA (Motorcraft
YN-12-C) or equivalent meeting Ford specification WSH-M1C231-B to the A/C condenser core or the suction accumulator/drier inlet tube.
5. Add 60 ml (2 ounces) of clean PAG Refrigerant Compressor Oil (R-134a Systems) F7AZ-19589-DA (Motorcraft YN-12-C) or equivalent
meeting Ford specification WSH-M1C231-B to the suction accumulator/drier inlet tube when carrying out each of the following repairs:
^
installation of a new A/C evaporator core orifice
^
installation of a new A/C compressor pressure relief valve
^
installation of a new refrigerant line
^
repair of an O-ring seal leak
^
repair of a charge port leak
6. Installation of new components that do not require discharge of refrigerant and resulting oil loss, such as the A/C cycling switch and the A/C
pressure transducer, do not require additional oil.
