Econoline E250 3/4 Ton V8-4.6L SOHC VIN W (2000)
Tail Lamp: Initial Inspection and Diagnostic Overview
Inspection and Verification
Special Service Tool(s)
Special Service Tool(s)
1. Verify the vehicle owner's original concern by operating the parking lamps to duplicate the original condition.
2. Inspect to determine if one of the following electrical concerns apply:
VISUAL INSPECTION CHART
^
Circuitry
^
Damaged connector
^
Bulb
^
Damaged headlamp switch
^
Blown fuse junction panel Fuse 10 (20A)
3. If the concern(s) remains after the inspection, determine the symptom(s) and proceed to the symptom chart. See: Symptom Related Diagnostic
Procedures
