Econoline E250 3/4 Ton V8-46L SOHC VIN W (2000) Auxiliary Climate Control Service
Hose/Line HVAC: Service and Repair
Auxiliary Climate Control
REMOVAL
1. Perform the Refrigerant Discharging and Recovery Procedure.
2. Disconnect the battery ground cable. For additional information, refer to Battery.
3. Partially drain the engine cooling system. For additional information, refer to Cooling System.
4. Remove the engine air cleaner (ACL) and the air cleaner outlet tube.
5. Disconnect the condenser core refrigerant lines.
1
Disconnect the compressor discharge line.
2
Disconnect the condenser to evaporator tube.
CAUTION: Use a wrench on each side of the fitting to prevent damage to the A/C fitting.
6. Disconnect the A/C evaporator core fitting.
1
Remove the screw.
2
Disconnect the A/C evaporator core fitting.
CAUTION: Use a wrench on each side of the fitting to prevent damage to the A/C fitting.
7. Remove the four clamps.
1
Remove the screw.
2
Remove the clamp.
8. Raise the vehicle.
