Econoline E250 3/4 Ton V8-4.6L SOHC VIN W (2000)
Liquid Vapor Separator: Service and Repair
REMOVAL
1. Remove the fuel tank. For additional information, refer to Fuel Delivery and Air Induction.
2. Remove the fuel vapor vent valve.
1. Slide the clamp away from the fuel vapor vent valve and remove the evaporative emission canister tube.
2. Press down and rotate the fuel vapor vent valve counterclockwise and remove from the fuel tank.
CAUTION: The fuel vapor vent valve must be disengaged from the fuel tank before it can be removed. While pressing down, rotate the fuel
vapor vent valve counterclockwise to disengage from the fuel tank. Failure to do so can cause damage to the fuel vapor vent valve or the fuel tank.
INSTALLATION
1. To install, reverse the removal procedure.
^
Carry out the evaporative emission system leak test. For additional information, refer to Evaporative Emission System Leak Test. See: Testing
and Inspection/Component Tests and General Diagnostics/Component Tests/Evaporative Emission System Leak Test
^
Carry out the evaporative emission repair verification drive cycle. For additional information, refer to Evaporative Emission Repair
Verification Drive Cycle. See: Service and Repair
