Econoline E250 3/4 Ton V8-4.6L SOHC VIN W (2000)
Axle Beam: Service and Repair
Axle Beam
Special Tool(s)
Removal
1. Raise and support the vehicle.
2. Remove the wheel and tire assembly.
3. Remove the disc brake caliper and brake disc and hub.
4. Remove the brake disc shield.
5. Remove the cotter pin and the castellated nut, using the Pitman Arm Puller disconnect the tie rod end.
