Econoline E250 3/4 Ton V8-4.6L SOHC VIN W (2000)
4
Remove the steering column opening lower finish panel reinforcement.
5. Disconnect the clockspring electrical connectors at the base of the steering column.
6. NOTE: Make sure the wheels are in the straight-ahead position.
Remove the steering wheel.
7. If so equipped, twist the tilt wheel handle and shank and remove.
8. Remove the lower steering column shroud.
1
Remove the three screws.
2
Remove the steering column shroud.
9. Remove the ignition switch lock cylinder.
