Econoline E250 3/4 Ton V8-4.6L SOHC VIN W (2000)
Special Tools
Special Tools
Disassembly
Note: When refilling the axle with lubricant, first add 21 C.L. (7 ounces) of Additive Friction Modifier C8AZ-19B546-A or equivalent meeting Ford
specification EST-M2C118-A.
1. Note: It is not necessary to remove the differential bearings to overhaul the limited-slip differential.
Note: In most cases it is possible to disassemble the unit without removing the differential ring gear, which saves the cost of new bolts.
If necessary, remove the differential ring gear.
2. Note: An axle shaft held in a vise, with the shaft splines extending not more than three inches above the vise jaws, makes an excellent holding
fixture for the differential case.
Using a small drift, remove the differential pinion shaft lock pin.
