Econoline E250 3/4 Ton V8-4.6L SOHC VIN W (2000)
Universal Joint: Service and Repair
Single Cardan , Slip Yoke
Special Tools
Disassembly
1
CAUTION: Under no circumstances is the driveshaft assembly to be clamped in the jaws of a vise or similar holding fixture. Denting or
localizing fracture can result, causing driveshaft failure during vehicle operation. Place the driveshaft on a suitable workbench. Be
careful not to damage the tube.
2. Note: If components are not marked and therefore installed incorrectly, driveline imbalance can occur.
Index-mark the driveshaft components.
3. Clamp U-joint tool in a vise.
4. Remove all four of the snap rings.
