Escape 2WD L4-122 2.0L DOHC VIN B SFI (2001)
Band Apply Servo: Service and Repair
Overdrive Servo
Special Tool(s)
Removal
1. NOTE: Servicing the intermediate/overdrive servo in the vehicle is only recommended in the event of a leak. If servicing is required due to a
servo condition, it is necessary to remove and disassemble the transaxle to inspect the intermediate/overdrive band assembly and direct clutch for
damage.
Raise the vehicle on a hoist.
2. WARNING: The servo is under pressure. Servo and servo cover are under high spring force. Use caution when removing servo cover.
Failure to follow these instructions may result in personal injury.
Assemble the special tool.
3. CAUTION: Do not use a screwdriver to remove the retaining ring or damage to the case may occur. Use only snap ring pliers to remove the
retaining ring.
Using the special tool, remove the servo assembly.
1. Install the special tool.
2. Compress the servo assembly by tightening the bolt.
3. Remove the retaining ring.
4. Remove the servo cover assembly.
5. Remove the intermediate and overdrive servo piston and return spring.
6. Wipe the servo piston and the servo cover cap with a lint-free cloth.
7. CAUTION: Do not clean the rubber sealing surfaces of the servo piston and the servo cover cap with cleaning solvent or damage to the sealing
surface may result.
