Escape 4WD L4-2.3L VIN H Hybrid (2005)

Page 1
background image

P2610 - P2614: Testing and Inspection
P2612

Hybrid Drive Related

For diagnosis of code P2612, refer to chart:

P0AAC-P2613 / U0001-U0300

If there is no link in the chart then:

-

This code is not a valid code for this vehicle
