Escape 4WD V6-181 3.0L DOHC VIN 1 Duratec (2003)
Cowl Moulding / Trim: Service and Repair
COWL PANEL GRILLE
Removal and Installation
1. Remove the wiper pivot arms.
1
Remove the nuts.
2
Remove the wiper pivot arm.
2. Remove the driver side cowl grille.
1
Remove the pin-type retainers.
2
Remove the screw caps and screws.
3
Remove the cowl grille.
3. Remove the passenger side cowl grille.
1
Remove the pin-type retainers.
2
Remove the screw caps and screws.
3
Remove the cowl grille.
4. To install, reverse the removal procedure.
