4. Tighten the wheel cylinder bleeder screw.

Front disc brakes

5. CAUTION:  Be sure to check the brake fluid level in the brake master cylinder reservoir often. Do not let it run dry.

Open the front disc brake caliper bleeder screw. Leave open until clear bubble-free brake fluid flows.

6. Tighten the front disc brake caliper bleeder screw.

7. Fill the brake master cylinder reservoir with fluid and install the reservoir cap.

^

Use High Performance DOT 3 Brake Fluid C6AZ-19542-AB or equivalent meeting Ford specification ESA-M6C25-A, DOT 3.

Brake System Manual Bleeding

Manual Bleed

WARNING:  Use of any other than the approved DOT 3 brake fluid will cause permanent damage to brake components and will render the
brakes inoperative. Failure to follow these instructions may result in personal injury.


WARNING:  Brake fluid contains polyglycol ethers and polyglycols. Avoid contact with eyes. Wash hands thoroughly after handling. If
brake fluid contacts eyes, flush eyes with running water for 15 minutes. Get medical attention if irritation persists. If taken internally, drink
