Escort L4-110 1.8L DOHC (1994)
Shift Cable: Adjustments
1. Shift gear selector lever to PARK position, then disconnect battery ground cable.
2. Remove shift console, then position indicator mounting screws.
3. Disconnect illumination bulb, shift-lock servo connector and park range switch connector.
4. Remove position indicator, then loosen shift control cable bracket mounting bolts.
5. Push gear selector lever against PARK range and hold in place.
6. Torque shift control cable bracket mounting bolts to 5.75-7.92 ft lb.
Adjusting Cable
7. Lightly press gear selector push rod and ensure guide plate and guide pin clearances are within specifications noted in image. If clearances are not
as specified, readjust shift control cable.
8. Reverse procedures 1 through 4.
