Diagram Information and Instructions|Page 1245 > < Diagram Information and Instructions|Page 1243

Escort L4-116 1.9L VIN J FI HP (1988)

Page 31
background image

Fuel Temp. & Low Coolant Warning Gauges Wiring Circuit W/Graphic Display. EXP

Diagram Information and Instructions|Page 1245 > < Diagram Information and Instructions|Page 1243
