Diagram Information and Instructions|Page 1290 > < Diagram Information and Instructions|Page 1288

Escort L4-116 1.9L VIN J FI HP (1988)

Page 76
background image

Hazard, Stop & Turn Lamps Wiring Circuit. 3 Door & 5 Door Hatchback (Part 2 of 2)

Fig. 39  Headlamps Wiring Circuit

Diagram Information and Instructions|Page 1290 > < Diagram Information and Instructions|Page 1288
