Diagram Information and Instructions|Page 1335 > < Diagram Information and Instructions|Page 1333

Escort L4-116 1.9L VIN J FI HP (1988)

Page 121
background image

Ignition & Starter Wiring Circuit With EFI

Ignition Lock

For Wiring Diagrams, please refer to: Starting System/Diagrams, See: Starting and Charging/Starting System/Diagrams
