Escort L4-122 2.0L SOHC (1997)
9. Install the (A) low/reverse clutch pressure plate and the (B) low/reverse clutch disc pack.
-
The installation order is steel-friction-steel-friction-steel-friction-steel-friction
10. Install the low/reverse clutch pressure plate snap ring.
11. With the low/reverse clutch assembled, check the low/reverse clutch disc pack clearance.
NOTE: Take several measurements and calculate the average value.
-
Use a feeler gauge to measure between the low/reverse clutch pressure plate and the low/reverse clutch pressure plate snap ring.
-
The clearance should be 2.1-2.4 mm (0.083-0.094 inch). If the clearance is not within the specification, adjust it by selecting the proper snap
ring. Refer to Snap Ring Sizes chart below.
2.0 mm (0.079 inch)
2.2 mm (0.087 inch)
2.4 mm (0.094 inch)
2.6 mm (0.102 inch)
2.8 mm (0.110 inch)
3.0 mm (0.118 inch)
