Escort L4-122 2.0L SOHC VIN P SFI (1999)
Clutch Disc: Specifications
Minimum Thickness
0.012 in
Maximum Runout
0.0276 in
Clutch Disc Inner Diameter
5.91 in
Clutch Disc Outer Diameter
8.86 in
Set Load
1.030 lb.
Clutch Disc Lining Thickness
Discard Thickness From Outer Face to Rivet Head
0.012 in
Flywheel Side
0.138 in
Pressure Plate Side
0.150 in
Maximum Runout
