Explorer 2WD V6-245 4.0L SOHC VIN E EFI (1997)
Brake Rotor/Disc: Specifications
Brake Rotor/Disc
Nominal Thickness
1.024 in
Minimum Refinish Thickness
0.974 in
For reference only. Always use specification found on
rotor.
Thickness Variation (Parallelism)
0.0004 in
Lateral Runout (T.I.R.)
0.003 in
Finish (Micro-Inch)
10-80 micro-in
Rear Disc Brake Rotor Nominal Thickness
0.472 in
Rear Disc Brake Rotor Minimum Thickness
0.409 in
Rear Disc Brake Rotor Inner Diameter
6.77 in
Rear Disc Brake Rotor Outer Diameter
10.16 in
Maximum Rotor Runout
0.003 in
Maximum Rotor Variation
0.0005 in
