Explorer 2WD V6-4.0L VIN K Flex Fuel (2002)

Page 1
background image

Compressor Clutch: Specifications
A/C Clutch Air Gap

A/C Clutch Air Gap

Air Gap (Between Clutch Plate and A/C Clutch Pulley)

0.014 - 0.030 Inch
