Diagram Information and Instructions|Page 7089 > < Diagram Information and Instructions|Page 7087

Explorer 2WD V8-302 5.0L VIN P EFI (1997)

Page 28
background image

^

Anti-Theft Relay

Power Distribution

Fuse 25

Fuse 25 - protects the following circuits:

^

Instrument Cluster

^

Generic Electronic Module

Power Source

Diagram Information and Instructions|Page 7089 > < Diagram Information and Instructions|Page 7087
