Explorer 4WD V6-245 4.0L VIN X SFI (1997)

  • Heating and Air Conditioning
  • Relays and Modules - HVAC
  • Blower Motor Relay
  • Component Information
  • Locations
  • With Electronic Automatic Temperature Control

Page 1
background image

Blower Motor Relay: Locations
With Electronic Automatic Temperature Control

Full Body View

The Rear Blower Motor Relay is located behind RH side of the instrument panel.
