Explorer 4WD V6-245 4.0L VIN X SFI (1997)
Power Distribution
Circuit-to-Fuse Cross Reference
Air Bag Diagnostic Monitor ................................................................................................................................................ Fuse 4 (10 Amp) & 7 (10 Amp)
Air Ride Control .......................................................................................................................................................................................................... Fuse 5
Auxiliary Power ........................................................................................................................................................................................................... Fuse 3
Daytime Running Lamp Module .................................................................................................................................................................................. Fuse 8
Fog lamp Relay ............................................................................................................................................................................................................ Fuse 8
Generator/Voltage Regulator ....................................................................................................................................................................................... Fuse 6
HEGO System ........................................................................................................................................................................................................... Fuse 11
