Explorer 4WD V6-245 4.0L VIN X SFI (1997)
Power Distribution Box
Circuit-to-Fuse Cross Reference
4 Wheel Anti-Lock Brake System (4WABS) Control Module .................................................................................................................................. Fuse 14
4WABS Main Relay .................................................................................................................................................................................................. Fuse 14
Accessory Delay Relay .............................................................................................................................................................................................. Fuse 27
Air Bag Diagnostic Monitor ............................................................................................................................................................................... Fuse 6 & 15
Anti-Theft Relay ........................................................................................................................................................................................................ Fuse 24
Autolamps ........................................................................................................................................................................................................... Fuse 9 & 11
