Diagram Information and Instructions|Page 2229 > < Diagram Information and Instructions|Page 2227

Explorer 4WD V6-245 4.0L VIN X SFI (1997)

Page 39
background image

Power Distribution (Part 17 Of 17)

Fuse 4

Fuse 4 - protects the following circuits:

^

LH Headlamp

^

Lamp Out Warning Module

Power Source

Power is supplied through the Multi-Function Switch
