Explorer 4WD V6-245 4.0L VIN X SFI (1997)

Page 52
background image

Power Distribution

Fuse 16

Fuse 16 - protects the following circuits:

^

Wiper Run Relay

^

Wiper High-Low Relay

^

Wiper Motor
