Explorer 4WD V8-302 5.0L VIN P SFI (2000)
Camshaft: Specifications
Intake lobe lift
0.2637 in
Exhaust lobe lift
0.2801 in
Maximum allowable lobe lift loss
0.005 in
End play
0.001 - 0.007 in
End play wear limit
0.009 in
Journal to bearing clearance
0.001 - 0.003 in
Service limit
0.006 in
No.1 journal diameter
2.0815 in
No.2 Journal diameter
2.0665 in
No.3 journal diameter
2.0515 in
No.4 journal diameter
2.0365 in
No.5 journal diameter
2.0215 in
Maximum camshaft journal runout 0.005 in
No.1 bearing inside diameter
2.0835 in
No.2 bearing inside diameter
2.0685 in
No.3 bearing inside diameter
2.0535 in
No.4 bearing inside diameter
2.0385 in
No.5 bearing inside diameter
2.0235 in
Front bearing location depth
0.005 - 0.020 in.
