Fuel Pump Relay|Locations|Page 4949 > < Powertrain Control Module Power Relay <--> [Main Relay (Computer/Fuel System)]|Locations|Page 4944

Explorer Sport Trac 2WD V6-245 4.0L SOHC VIN K SFI (2001)

Page 1
background image

Diagram 700-01-00-2

Fuel Pump Relay|Locations|Page 4949 > < Powertrain Control Module Power Relay <--> [Main Relay (Computer/Fuel System)]|Locations|Page 4944
