Explorer Sport Trac 2WD V6-245 4.0L SOHC VIN K SFI (2001)
Suspension Spring ( Coil / Leaf ): Specifications
Spring Shackle Lower Bolt and Nut
Rear
85 ft.lb
Spring to front frame Bracket and nut (E-coated frame)
85 ft.lb
Spring to front frame bracket bolt and nut (wax-coated frame)
111 ft.lb
Spring U-bolt nut
76 ft.lb
Jounce Bumper nut
15-21 ft.lb
