Explorer Sport Trac 4WD V6-4.0L VIN E (2007)
Seals and Gaskets: Service and Repair
Extension Housing Gasket
Extension Housing Gasket - Four Wheel Drive (4WD)
Removal
1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to Maintenance/Service and Repair.
2. Support the transmission with a suitable jack.
3. Remove the transfer case.
4. CAUTION: The parking pawl, parking pawl return spring and parking pawl shaft could fall out during removal of the extension
housing.
Remove the extension housing.
5. Remove and discard the extension housing gasket.
Installation
1. Clean the extension housing and install new extension housing gasket. Make sure that the park pawl is installed correctly.
2. CAUTION: Make sure the parking lever actuating rod is correctly seated into the case parking rod guide cup.
Install the extension housing.
^
Tighten to 30 Nm (22 ft. lbs.)
