Explorer Sport Trac 4WD V6-4.0L VIN K Flex Fuel (2004)
Ignition Coil: Service and Repair
IGNITION COIL
REMOVAL
1. Disconnect the battery ground cable.
2. Disconnect the ignition coil electrical connector.
3. CAUTION: It is important to twist the spark plug wire boots while pulling upward to avoid possible damage to the spark plug wire.
NOTE: Spark plug wires must be connected to the correct ignition coil terminal. Mark spark plug wire locations before removing them.
Squeeze the locking tabs and twist while pulling upward to disconnect the six spark plug wires.
4. Remove the bolts and the ignition coil.
INSTALLATION
1. NOTE: Apply silicone dielectric compound to the inside of the spark plug wire coil boots.
To install, reverse the removal procedure.
