F 150 4WD Pickup V8-5.4L CNG VIN M (2001)

Pressure Regulating Solenoid: Service and Repair
Electronic Pressure Control (EPC) Solenoid
Special Tool(s)
Removal
1. Remove the manual control lever.
2. CAUTION: Do not pull on the molded lead frame. This may cause damage to the connector ends. Carefully pry up on the locking tabs to
disconnect the solenoids. Disconnect the molded lead frame from the solenoids.
Disconnect the molded lead frame from the solenoids.
1. Disconnect the shift solenoid SSA and SSB.
2. Disconnect the torque converter clutch (TCC).
3. Disconnect the electronic pressure control (EPC) solenoid.
4. Disconnect the bulkhead inter-connector.
3. Remove the EPC solenoid.
