F 250 2WD Pickup V8-302 50L (1983) | Windshield Washer Switch Diagram
Windshield Washer Switch: Diagram Information and Instructions
Symbol Identification
Wire Color Code Identification
NOTE: Whenever a wire is labeled with two colors; the first color listed is the basic color of the wire, and the second color is the tracer marking
of the wire. If the second color is followed by by a D, the tracer is dots. If the second color is followed by an H, the tracer is hash marks.
For example: BR/O is a brown wire with an orange stripe, R/Y D is a red wire with yellow dots and BK/W H is a black wire with white hash
