F 250 2WD Pickup V8-351 5.8L (1982)
Headlamp Switch: Service and Repair
Fig. 6 Light Switch
F-100---350 & BRONCO
1.
Disconnect battery ground cable.
2.
Remove knobs from headlight switch, windshield wiper switch and fog light switch (if equipped). Use a suitable hook tool to release each knob
lock tab.
3.
Remove steering column shroud, then the cluster finish panel assembly, Fig. 5.
4.
Remove switch attaching nut, Fig. 5.
5.
Disconnect electrical connector from switch and remove switch from vehicle.
6.
Reverse procedure to install.
