F 250 2WD Pickup V8-351 5.8L (1982)
Transmission Linkage: All Technical Service Bulletins
M/T - Broken/Damaged Interlock Plates
Article No. 83-4-20
TRANSMISSION - MANUAL - SROD - INTERLOCK PLATE DAMAGED/BROKEN
LIGHT TRUCKS 1980-82 BRONCO & F-100/250
Damaged or broken interlock plates may be due to an interference condition between the reverse gearshift relay lever assembly and the gear selector
interlock plate. The interference occurs while shifting into reverse gear.
Figure 9
Remove the reverse gearshift relay lever assembly and the gear selector interlock plate. Replace the gear selector interlock plate with a new plate
D9BZ-7K201-A and grind the reverse gearshift relay lever as shown in Figure 9.
For teardown and build-up procedures, refer to appropriate Shop Manual, Chassis Volume, Section 16.
PART NUMBER
PART NAME
CLASS
D9BZ-7K201-A
Interlock Plate
B
OTHER APPLICABLE ARTICLES: None
WARRANTY STATUS: Reimbursable within the provisions of the Warranty and Policy Manual.
OPERATION: SP 7001-A-83
TIME:
2.8 Hrs. - 4x2 4.3 Hrs. - 4x4 DLR. CODING: Basic Part No. 7K201 Code: 16
